Water Cooled Chiller

PRODUCT DESCRIPTION:

1. The German high-efficiency semi-closed twin-screw compressor is used to greatly improve the adiabatic efficiency. 2. We have passed the two major certifications of AHRI and CRAA, which is the highest level organization in the international refrigeration industry. 3. The original three-stage oil return system has an oil return efficiency of 99.9%. 4. Use R134a refrigerant, in line with international environmental standards.

Product Details

1. The German high-efficiency semi-closed twin-screw compressor is used to greatly improve the adiabatic efficiency.

2. We have passed the two major certifications of AHRI and CRAA, which is the highest level organization in the international refrigeration industry.

3. The original three-stage oil return system has an oil return efficiency of 99.9%.

4. Use R134a refrigerant, in line with international environmental standards.

Specifications

Model		TWSF-DC2	0115.1	0140.1	0175.1	0215.1	0245.1	0285.1	0320.1	0345.1	0380.1	0285.2
Cooling Capacity		Ton	115	141	175	215	246	283	321	344	383	283
		10⁴ kcal/h	35	42	53	65	74	86	97	104	116	86
		KW	404	494	616	757	864	996	1127	1208	1345	996
Input power		KW	71	86	108	132	150	174	196	208	232	174
Energy Efficiency Ratio		KW/Ton	0.618	0.612	0.616	0.613	0.610	0.614	0.611	0.605	0.606	0.614
COP		WW	5.69	5.74	5.70	5.73	5.76	5.72	5.75	5.81	5.80	5.72
Running Current		A	124	161	183	204	229	257	286	319	359	322
Starting Current		A	268	378	379	488	617	684	845	965	917	583
Number of Compressors		Unit	1	1	1	1	1	1	1	1	1	2
Evaporator	Water flow	m³/h	69	85	106	130	149	171	194	208	231	171
	Water pressure drop	kPa	68	66	66	65	67	66	68	66	69	79
	Pipeline DN	mm	150	150	150	150	150	200	200	200	200	200
Condenser	Water flow	m³/h	82	100	125	153	174	201	228	244	271	201
	Water pressure drop	kPa	64	63	63	63	61	59	62	62	62	72
	Pipeline DN	mm	150	150	150	150	150	200	200	200	200	200
Dimensions	Length	mm	3097	3097	3097	3097	3097	3124	3124	3124	3124	4854
	Width	mm	1530	1530	1530	1530	1530	1800	1800	1800	1800	1670
	Height	mm	1820	1820	1820	1820	1820	1920	1920	1920	1920	2070
Shipping weight		kg	2670	2880	3110	3325	3635	3930	4155	4375	4570	5460
Running weight		6	2860	3070	3330	3575	3935	4230	4455	4675	4870	5810
