Air Cooled Chiller

PRODUCT DESCRIPTION:

1. TASD series air-cooled screw chillers adopt modular design and are air-conditioningmain equipments that provide cold water for central air-conditioning terminalequipment. 2. The suppliers of refrigeration accessories and control components are selected fromworld-famous manufacturers, coupled with the most advanced intelligent controlschemes, making the unit efficient, energy-saving, stable and reliable. 3. With multi-machine joint control function, up to 8 units can be connected to control,optional built-in hydraulic module, and can be connected with building control system(BAS), easily meet the air conditioning needs of different occasions. 4. The unit can be widely used in hotels, hospitals, office buildings, shopping malls,apartments, factories and other comfort and craft occasions.

Product Details

1. TASD series air-cooled screw chillers adopt modular design and are air-conditioningmain equipments that provide cold water for central air-conditioning terminalequipment.

2. The suppliers of refrigeration accessories and control components are selected fromworld-famous manufacturers, coupled with the most advanced intelligent controlschemes, making the unit efficient, energy-saving, stable and reliable.

3. With multi-machine joint control function, up to 8 units can be connected to control,optional built-in hydraulic module, and can be connected with building control system(BAS), easily meet the air conditioning needs of different occasions.

4. The unit can be widely used in hotels, hospitals, office buildings, shopping malls,apartments, factories and other comfort and craft occasions.

Specifications

TASD-AC1			110.1	145.1	170.1	210.1	230.2	260.2	285.2	335.2
Cooling capacity		kW	385	505	601	730	808	909	1001	1171
Cooling capacity		kcal/h	331100	434300	516860	627800	694880	781740	860860	1007060
Cooling input power		kW	123	159	189	233	254	285	319	371
Cooling rated current		A	219	288	341	419	479	507	578	665
Maximum starting current		A	615	845	845	965	1102	1264	1358	1358
Maximum operating current		A	419	513	523	521	900	932	1026	1026
Power		380V 3N~ 50Hz
Water side heat exchanger	Type	High efficiency shell and tube water side heat exchanger
	Cooling water flow	m3/h	66	87	103	126	139	156	172	201
	Pipe DN	DN	125	125	125	150	150	150	150	200
	Water pressure drop	kPa	40	53	56	57	68	72	73	70
	Water side pressure	MPa	1
Compressor	Type	Semi-closed screw
	Energy adjustment range	25%-100%Four-level adjustment					12.5%-100%Eight-level adjustment
	Startup type	Star triangle connection
Fan	Air volume	m3/h	150000	200000	250000	250000	350000	350000	400000	400000
Fan	Quantity	Set	6	8	10	10	14	14	16	16
The refrigerant	Type	R134a
	Number of working systems		1				2
	Charge	kg	86	100	115	150	186	186	200	230
Dimensions	Length	mm	3787	4792	5797	5797	8707	8707	9712	9712
	Width	mm	2250
	High	mm	2420				2480
Hydraulic module (optional)	Built-in hydraulic module (optional)	Pumps, expansion tanks, filters, safety valves, pressure gauges, butterfly valves, etc.
Hydraulic module (optional)	Pump type	Centrifugal single or dual pump (optional)
Shipping weight		kg	4350	4690	5500	6050	7850	7980	9200	9550
Running weight		kg	4550	4910	5750	6340	8190	8340	9590	9980
